ADAS DSM BSD Car Dash Camera Dual Lens GPS Quadruple 1080P RS232
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | OEM |
| Certification: | CE ROHS FCC |
| Model Number: | OX-ZP904 |
Payment & Shipping Terms:
| Minimum Order Quantity: | ONE SET |
|---|---|
| Price: | Negotiated |
| Packaging Details: | Neutral Packing |
| Delivery Time: | 15working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability: | 10000pcs/month |
|
Detail Information |
|||
| Sensor: | CMOS | Relosution: | 1920*1080 |
|---|---|---|---|
| Main Chip: | HI3520dV400 | Storage: | Two Micro SD(MAX.256G) |
| Feature: | ADAS And DMS Algothim | Wifi: | IEEE802.11b/g/n |
| Highlight: | Quadruple 1080P Car Dash Camera,ADAS DSM BSD Car Dash Camera,RS232 Dual Dashboard Camera |
||
Product Description
| General Setting | |
| Main Chip | Hi3520dV400 |
| RAM | 4GB |
| Outside Camera |
2.0MP sensor,150°wide angle Support wide dynamic (WDR) |
| Inside Camera |
2.0MO sensor,150°wide angle Infrared night vision,the video is clearly visible in the dark environment |
| Double TF Card | Support double TF card,32GB/64GB/128G/256G |
| Positioning | Beidou/GPS Dual-mode high-precision positioning module |
| Gryo | Collision alarm,vibration alarm |
| microphone and speaker | Built-in |
| ADAS algorithm (Optional) | Advanced driving assistance system:lane deviation alarm,forward collision alarm,and closer distance alarm |
| DSM algorithm + DSM Camera | Driver behavior analysis: head down,call,smoke, look around,yawn, close eyes,no face detected,cover the camera |
| Face Recognition algorithm (Optional) | Identify the driver and report to the platform |
| Video Parameters | |
| Video Resolution | 1080P/720P/D1 |
| Video Format | H265/H264 |
| File format | Special file system,support asf file exported |
| Network Parameters | |
| 4G |
Support all networks in China Mainland:China Mobile,China Unicom,China Telecom,IoT card. Worldwide network in oversea. |
| WIFI | 2.4G GHZ,Support WIFI STA/AP WIFI,Support mobile preview |
| External Connection | |
| VCC | Power supply 9V-36V |
| GND | Ground |
| ACC | Ignition detection,control power on or off |
| SOS Key | Emergency button,video upload before and after the police |
| PTT Key | Short press to take pictures,long press to talk |
| External display | CVBS port,Video output |
| Serial port | One set RS232,Support extension |
| Two external cameras | 2 sets of AHD port Camera |
| USB | MINI USB port,Support video data copying,equipment upgrade, mouse operation |
| Size | |
| Working environment | |
| Operation temperature | -20℃~+70℃ |
| Operation humidity | ≤93% |
Web/Mobile APPAPP latform
