Product Details:
|
| Storage: | Cloud | Battery: | Build In NTC Lithium Battery 21700mah |
|---|---|---|---|
| Night Vision: | Support | Video Code: | H264/H265 |
| Name: | PTZ Dome Camera | Audio Communication: | 2 Way Audio Communication |
| High Light: | Dome 4G PTZ Camera,200W 4G PTZ Camera,850nm Infrared PTZ Dome Camera |
||
WIFI Solar Dome Camera Main Domain Controller:Hisilicon Hi3518EV300 1080P/ 2.0MP 2-Way Audio Communication Security Cam
Parameters
| Product name | TY500 Solar WiFi camera |
| Module | Hisilicon Hi3861 low power wi-fi chip |
| Frequency | 2.4Gwifi |
| Distribution network | Qr code scanning+Wi-Fi Quick link |
| SIM card | Not Supported |
| WiFi hotspot | Not Supported |
| Video code | H264/H265 |
| AEESS | Support |
| ANGLE |
Horizontal:320° Vertical:90° |
| Key | Power/reset key |
| Status | LED (blue & red) |
| Memory Card | Support TF Card 4GB-64GB and cloud storage |
| Playback | Event list and cloud storage playback |
| Grade of waterproof | IP66 |
| Full duplex intercom | support |
| APP | Tuya smart,ios10.0,android5.0 |
| Temperature | -30℃ ~+60℃ |
| Humidity | ≤80%RH |
| Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P |
| Main Domain Controller | Hisilicon Hi3518EV300 |
| Image Sensor | 200W 1080P CMOS sensor SC2335 1/2.8 |
| Video Streaming | 1920*1080/15fps 640*360/30fps |
| Mobile detection | PIR + mobile detection + humanoid detection multiple intelligent detection, effective distance 10 meters |
| Night vision mode | 850nm infrared +White light,App selection |
| Night vision distance | effective lighting distance of about 10m |
| Camera lens | 3MP High definition camera 3.6MM F=2.8 level FOV 120 degrees |
| Battery | 8*18650 lithium battery, solar rechargeable battery |
| Charge | 3.5W solar power continuous charging, support USB port about 16 hours full charge |
| Wake up/sleep time | 15s no sleep |
| System | Lite OS |
Specification
WIFI solar dome camera
* Main Domain Controller:Hisilicon Hi3518EV300
* 1080P/ 2.0MP
* Support cloud storage
* Support 2-way audio communication, support mobile APP remote, support alarm push
* Support PIR detection alarm, support active viewing
* Charge:With 8W solar power continuous charging, support USB port about 16 hours full charge
* Battery:Build in NTC lithium battery 21700mah, solar rechargeable battery
* Dual light source night vision full color
* Waterproof:IP66, support outdoor use
* Power supply mode: 18650 battery power supply; USB power supply
* Video codec:H264/H265
* ANGLE:Horizontal:320°,Vertical:90°
* Power consumption: standby current 250uA; working current 170mA
* APP:Tuya smart
Features
