Product Details:
Payment & Shipping Terms:
|
| Rang: | 150-200m | ||
|---|---|---|---|
| High Light: | FCC Voice Control Wireless Baby Monitor,5inch Display Wireless Baby Monitor,ROHS Wireless Video Monitor |
||
Specification
| Specification | Detail |
| FPS | 15-25 FPS |
| Signal intensity | 5 level |
| Volume Control | 10 level |
| intercom | Two-way communication |
| Voice control | Auto, with alarm function |
| One receiver multiple emitters | One receiver with four emitters,switch display and loop display support |
| Screen size and resolution | 5-inch, 720*1280 RGB, color LCD |
| Secure transmission | Code needed |
| Working Time | 5 hours of continuous discharge, 8 hours of sleep mode |
| LCD receive voltage | DC:5V/1000MA |
| Battery | Built-in 3.7V/2020MAH Li-battery |
| Transmission Frequency | 2.4GHz ISM Band |
| Wireless working method | FHSS |
Transmission power |
17+-1dBm |
| Transmission speed | 4MHz BER<1E-3 |
| Transmission distance | 150-200 meters in open area |
| Working Electric current | TX:500mA MAX,RX:500mA MAX , stand-by 340MA (without charging Electric current) |
| Charging Electric current | 300-400MA |
| Camera resolution | 720P |
| Image resolution | 720P |
| Video frame rate | 15-25FPS |
Total Harmonic distortion |
<5.0% |
Signal to Noise Ratio |
46dB |
| Reception sensitivity | -89dBm(Typ.)@4MHz BER<1E-3 |
| Night vision distance | 3—5 meter (6 LED Lights) |
| Humidity | 20--80% RH |
| Temperature | 0℃--45℃ |
