4CH SD card Mobile DVR Dashboard Support multi-channel comparison playback
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM/ODM |
| Certification: | CE, ROHS FCC |
| Model Number: | OX-MD204-4CH |
| Document: | MD214-4CH 4G SD card Mobile...n.docx |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Gift Box Size:16*15*7.5cm |
| Delivery Time: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000/pcs/month |
|
Detail Information |
|||
| Video Channel: | 4 Channels, 1 To 4 Video Channels Are Optional, 4 Audio Channels | Resolution: | Support 4 Channels 1080P, 720P, D1, CIF, Etc. |
|---|---|---|---|
| Video Compression Format: | H.265/H.264 Compression Format | Alarm Input: | 4CH Alarm Inputs, With Alarm Linkage Function |
| Highlight: | SD card Mobile DVR Dashboard,4CH Mobile DVR Dashboard |
||
Product Description
Product features
1.Industrial design, stable and reliable, easy to install
2.Video adopts the international mainstream H.265/H.264 encoding format, and the audio adopts G711a encoding. It can support up to 4 channels of 1080P. high compression ratio , clear image, and Use small disk space .
3.Professional vehicle power supply, can adapt to 8 to 36V ultra-wide voltage input, with multiple protection circuits such as overload/short circuit/reverse connection
4.Highly reliable aviation plug input and output interface, easy to install and plug, and stronger Vandal-proof performance
5.Support 4 channels of video and audio input, frame rate and image quality are adjustable
6.Support single SD card Max 512G large capacity recording
7.The video content has the power-off protection function, and the video will be automatically restored when power recovery
8.Support video loss alarm function
9.Independent delay Power shutdown , can support the system to continue running after the vehicle is turned off, the delay time can be set by yourself
10.Support MDVPlayer and standard players, provide playback, analysis, management and other functions
11.Support Firmware upgrade via U disk
12.Choose GPS function
| Item | Description | Feature |
|
Video subsystem |
Video channel | 4 channels, 1 to 4 video channels are optional, 4 audio channels |
| Resolution | Support 4 channels 1080P, 720P, D1, CIF, etc. | |
| Video quality | Multiple levels are optional | |
| OSD | Various characters can be superimposed, such as date and time and channel ID, etc. | |
| Loop recording | Support SD card loop recording and loop coverage | |
| Video mode | Support boot recording, timing recording, alarm trigger recording | |
| Preview | Support single screen and multi screen | |
|
Playback subsystem |
Video search | Supports search at any time within a certain day, and multiple search types are supported |
|
Replay |
Support multi-channel comparison playback | |
| Support fast forward and fast rewind, respectively supporting 2, 4, 8, 16 times speed optional | ||
| Support alarm point search and time point search | ||
| GUI | Graphical interface | Support configuration of various parameters through the MDVR menu |
|
other |
Power ON/OFF | Support delay power on/off |
| Support key power on/off and time power on/off machine |
