Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch

China Shenzhen Ouxiang Electronic Co., Ltd. certification
China Shenzhen Ouxiang Electronic Co., Ltd. certification
OUXIANG is very professional and fast service,Have very strong, ODM development capabilities, fast delivery orders, trustworthy company,No complaints. Thank you!

—— Mazi from Canada

OUXIANG is a very strong R & D capability, I have found more than 10 factories can not do, they successfully completed my project, very good, thanks

—— Keith From USA

The quality and service are good, delivery time is punctual every tim, 24 hours at any time to contact, order delivery, ouxiang trustworthy company

—— Oscar from Sweden

I'm Online Chat Now

Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch

Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch
Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch

Large Image :  Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Oxiang/ OEM/ ODM
Certification: CE, RoHS, FCC
Model Number: B2B241230
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Box Size:28*22*10cm
Delivery Time: Sample: Around 3 working days after payment
Payment Terms: T/T, Western Union, MoneyGram, Paypal, Credit Card
Supply Ability: 10000pcs/month
Detailed Product Description
Input Voltage: 24V(21-32V) Output Voltage: 12V(10.5-16.0V)
B2B Charging Current: 12V, 30A Max.charging Power: 390w
Charge Battery Type: Lead-acid,GEL,Sealed,Flooded, LiFePO4, Lithium-ion Product Size: 190×194×70mm
High Light:

ODM DC DC Battery Charger

,

390w DC DC Battery Charger

,

DIP Switch dc dc smart charger



DC-DC Battery Charger Automatic Smart DC Battery Charger





Parameters





Input "T T" for Battery Temperature Sensor "Board I": YES
" Ss-" "Ss+" Inputs Sensor Cables "-" and "+" for Battery "Board I": YES
stand-by current 24mA
Main battery overvoltage protection 15.5V
weight 1.44kg
demension 190×194×70mm
Operating temperature -20-50ºC



Lead-Acid, Gel, AGM Batteries Nominal Voltage 12V
LiFePO4 Nominal Voltage 12.8V
lithium- ion( NCM) Nominal Voltage 11.1V
Capacity (Battery Size), recommended: 45-280AH
Vehicle Starter Battery "Start II":
Vehicle Starter Battery Nominal Voltage: 12V
Min. Battery Capacity (Size), recommended: 60AH
12 V / 12 V B2B Charging operation



Description





Compact in size, easy to install and fully sealed - water, dust and vibration are no match for our vehicle battery chargers. Suitable for 12 or 24 volt vehicle systems, Oxiang's dual battery chargers work with either standard, voltage alternators or smart alternators.



DC to DC battery chargers



Getting a dead battery when you’re off on a 4WD or caravan adventure is the worst. However, with some of the most powerful and compact DC DC battery chargers has to offer. No matter what kind of battery charging system you're after,Oxiang has the solution. Our wide selection of DC to DC battery chargers are designed to keep your battery charged whilst driving and will fully charge auxiliary batteries to a proven 100%.*

*large capacity battery banks may require a few cycles to fully charge.






Function



Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch 0Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch 1Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch 2Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch 3Automatic Smart DC DC Battery Charger 390w Compact Size DIP Switch 4





Why Choose us?



> Oxiang is located in Shenzhen, China, a new type of city in rapid development. We focus on CCTV Camera researching and manufacturing from 2006;



> Sales person provide Pre-sales and after-sales service; Professional engineers are always standby and assist offer solutions;



> Cooperate with multiple departments to complete raw material procurement, production, inspection, delivery and other steps;



> The product comes with a one-year warranty.
